EC

Our electrochromic film technology provides a cost-effective and energy-saving solution for businesses seeking to control light and privacy. Utilizing a redox process, the film adjusts its tint based on the amount of electrical charge applied. This results in not only energy savings but improved comfort as well, as the film can be programmed to automatically adjust its tint based on the environment or be manually controlled.

Our roll-to-roll production process enhances the film's strength and versatility, making it ideal for easy application on even curved surfaces. This state-of-the-art production method also makes the film faster to produce and more cost-effective. Investing in our electrochromic film technology is a smart choice for businesses that want to reduce their energy consumption and minimize their environmental impact while gaining improved comfort and control over light and privacy in their space.

EC

Our electrochromic film technology provides a cost-effective and energy-saving solution for businesses seeking to control light and privacy. Utilizing a redox process, the film adjusts its tint based on the amount of electrical charge applied. This results in not only energy savings but improved comfort as well, as the film can be programmed to automatically adjust its tint based on the environment or be manually controlled.

Our roll-to-roll production process enhances the film's strength and versatility, making it ideal for easy application on even curved surfaces. This state-of-the-art production method also makes the film faster to produce and more cost-effective. Investing in our electrochromic film technology is a smart choice for businesses that want to reduce their energy consumption and minimize their environmental impact while gaining improved comfort and control over light and privacy in their space.






Principal and Structure
  • When external voltage is applied, the color of the material changes due to oxidation/reduction reactions in the EC Layer or Ion Storage Layer.

  • The driving voltage is as low as 1~3V, and the switching speed is usually proportional to the area.

Features
Comport
Anti-glare
Low energy consumption
UV blocking
Energy saving

Smart control
Principal and Structure
  • When external voltage is applied, the color of the material changes due to oxidation/reduction
    reactions in the EC Layer or Ion Storage Layer.

  • The driving voltage is as low as 1~3V, and the switching speed is usually proportional to the area.

mobile background
Features

Comport


Anti-glare


Low energy consumption


UV blocking

Energy saving

Smart control
Specification
Specification
Blue
Black
Size
Width
≤ 1500mm
≤ 1500mm
Length
No limit
No limit
Thickness (Film)
350㎛
350㎛
Drive Method
Applying DC Voltage
Applying DC Voltage
Voltage Amount
1.5 to 3V
1.5 to 3V
Colored State
Charged
Charged
Bleached State
Charged
Charged
Type
Battery Type / Memory Effect
Battery Type / Memory Effect
Consumption Energy when it is switching
≤ 0.01Wh/m2
≤ 0.01Wh/m2

Time

1000mm Width

Coloring
≤ 30 minutes
≤ 25 minutes
Bleaching
≤ 20 minutes
≤ 15 minutes

VLT

Visible Light Transmittance

Colored
8.0%
10.0%
Bleached
67.0%
60.0%
UVT

Ultraviolet Transmittance

Colored
≤ 0.1%
≤0.1%
Bleached
≤ 0.1%
≤0.1%
SHGC

Solar Heat Gain Coefficient

Colored
≤ 0.15
≤0.15
Bleached
≥ 0.45
≥0.45
Note
Multiple Tinting Level
Multiple Tinting Level

Orion NES

Application section
Building
Window

If the electrochromic smart window is
applied, the heating and cooling energy
usage rate of the building can be reduced
by more than 30%. The electrochromic
film can be applied not only to
newbuildings but also to existing
buildings, so it can enter the retrofit
market of buildings.













Building
Window

If the electrochromic smart window is
applied, the heating and cooling energy
usage rate of the building can be reduced
by more than 30%. The electrochromic
film can be applied not only to
newbuildings but also to existing
buildings, so it can enter the retrofit
market of buildings.













Transportation
Window

The automobile window with
electrochromic film can actively control
visible light and solar energy entering
theinterior. Also, it can be applied to
automatic dimming rearview mirrors
and side mirrors. These can significantly
reduce drivers' glare.













Transportation
Window

The automobile window with
electrochromic film can actively control
visible light and solar energy entering
theinterior. Also, it can be applied to
automatic dimming rearview mirrors
and side mirrors. These can significantly
reduce drivers' glare.













Eyewear

Eyewear with electrochromic film is
convenient because there is no need to
take off eyewear. If you want to see clear,
please click the button to switch its color,
or if you set it to automatic mode, you
don’t need to care about it.












Eyewear

Eyewear with electrochromic film is
convenient because there is no need to
take off eyewear. If you want to see clear,
please click the button to switch its color,
or if you set it to automatic mode, you
don’t need to care about it.












Display

The electrochromic film can enhance
display the contrast of transparent
displays. When the lights are too strong
to watch transparent displays, the
electrochromic film can block the light.
And you can still see beyondthe display.











Display

The electrochromic film can enhance
display the contrast of transparent
displays. When the lights are too strong
to watch transparent displays, the
electrochromic film can block the light.
And you can still see beyondthe display.











Building
Window

If the electrochromic smart
window is applied, the heating
and cooling energy usage rate
of the building can be reduced
by more than 30%. The
electrochromicfilm can be
applied not only to newbuildings
but also to existing buildings,
so it can enter the retrofit
market of buildings.













Building
Window
Transportation
Window

The automobile window with
electrochromic film can actively
control visible light and solar
energy entering the interior.
Also, it can be applied to
automatic dimming rearview
mirrors and side mirrors.
These can significantly reduce
drivers' glare.













Transportation
Window
Eyewear

Eyewear with electrochromic
film is convenient because there
is no need to take off eyewear.
If you want to see clear, please
click the button to switch its
color, or if you set it to automatic
mode, you don’t need to care
about it.













Eyewear
Display

The electrochromic film can
enhance display the contrast of
transparent displays. When the
lights are too strong to watch
transparent displays, the
electrochromic film can block the
light. And you can still see
beyondthe display.













Display
